Industrial PC Super 7

$1,118.00

Powered by multi-core processors, Super 7 industrial PC delivers low-latency control and deterministic execution. Tested for CODESYS, it supports IEC 61131-3 PLC programming and integrates with EtherCAT, PROFINET, Modbus TCP, and Ethernet/IP protocols. Its fanless, wide-temperature design ensures reliable 24/7 operation in harsh industrial environments. Supporting OPC UA and Node-RED for IoT and edge computing applications, along with flexible serial and Ethernet I/O interfaces, it offers versatile connectivity and expansion options.

Features:

Fanless panel PC with built-in display
7" LCD with resistive touch screen
Intel® Celeron® Processor J6412
2 x 2.5GbE, 3 x COM, DVI, HDMI, 4 x USB
Wide Range 9~36V DC input
Plastic (ABS) housing
Supports IEC 61131-3 PLC programming
Integration with EtherCAT, PROFINET, Modbus TCP, and Ethernet/IP protocols
Built for harsh environments and 24/7 uptime
Supports OPC UA and Node-RED
Serial and Ethernet I/O interface

Software License:

Choose "None" for industrial PC with Linux OS installed.
Choose "CODESYS PLC Control" or "CODESYS Motion Control" for plug-and-play solutions.

Motherboard	3I640CW
CPU	Intel® Celeron® Processor J6412
Chipset	Intel® Elkhart Lake SoC
Memory	4GB
Storage	M.2-SSD 128GB
I/O ports	Network: 2 x Intel 2.5 GbE
	USB: 2 x USB 3.0, 2 x USB 2.0
	Serial ports: 2 x RS232 / 422 / 485, 1 x RS232
	Display: 1 x DVI, 1 x HDMI
	HD Audio: Line-out / Mic-in
OS support	Linux Debian 10
Dimensions	L225.3 x W166.8 x H66.09 mm
Weight	1.2 kg
Mounting	Panel Mount
DC input	+9~36V
AC input	External adapter 100 / 240V, AC-DC (optional)
Display Type	7 inch 16:9
Max. Resolution	1024 x 600
Viewing Angle	75(U) 75(D) 75(R) 75(L)
Luminance (cd/m2)	500
Contrast Ratio	700:01:00
Touch Type	Resistive Touch Screen
Operating Temp. (100 % CPU usage)	-20°C to +60°C
Storage Temp.	-20°C to +70°C
Relative Humidity	95% @ 40°C, non-condensing
IP Rating	Front panel IP65 Compliant
Certification	CE / FCC

IPC hardware only: Standalone Industrial PC with Linux OS installed. No CODESYS. Suitable for gateway, edge computing and other applications.
IPC controller (IPC + CODESYS PLC control): Industrial PC with Linux OS installed, PREEMPT_RT kernel configured, CODESYS Control Basic M licensed. Suitable for PLC applications with less than 128 I/O, minimum number of field buses, and Linux applications. Plug-and-play, ready to use out of the box.
IPC motion controller (IPC + CODESYS motion control): Industrial PC with Linux OS installed, PREEMPT_RT kernel configured, CODESYS Control Standard M and 4 SoftMotion Axes licensed. Suitable for PLC applications with 4 axes motion control capability, numerous field bus communication, and small scale linux applications. Plug-and-play, ready to use out of the box.

If your application is requires different configuration or licensing to our standard offerings, we recommend choosing the "None" option for software license add-ons. Our support engineer will guide you through the installation process.
